Dimensions and Weights
|
| Overall
length |
2170
mm |
| Overall
width |
970
mm (over mirrors) |
| Wheelbase |
1487mm |
| Seat
height |
800
mm |
| Weight
- wet |
525
lbs |
| Maximum
load |
992
lbs |
| Top speed |
122 mph |
General
|
| Type |
2-cylinder
4-stroke flat twin |
| Bore
x stroke |
101
mm x 70.5 mm |
| Displacement |
1130
cc |
| Horsepower |
85
bhp |
| Torque |
98Nm |
| Compression
ratio |
10.3 |
| Valve
control |
HC |
| Valves |
2x34mm
intake / 2x29mm exhaust |
| Valves
per cylinder |
4 |
| Fuel
supply |
Motronic
MA 2.4 |
| Fuel
capacity |
5.4
gallons |
| Alternator |
700W |
| Battery |
12V/19Ah |
| Cooling
system |
Water/oil |
Drivetrain
|
| Clutch |
Single
plate dry clutch, 165mm in diameter |
| Gear
ratios |
1st
gear: 2.045/2.82
2nd gear: 1.6/2.82
3rd gear: 1.267/2.82
4th gear: 1.038/2.82
5th gear: 0.9/2.82
6th gear: 0.8/2.82 |
Frame and Suspension
|
| Frame |
tubular
spaceframe, engine serving as loadbearing component |
| Travel/Dimensions |
120mm |
| Travel/Dimensions |
135mm |
Brakes
|
| Front
brakes |
dual
disc |
| Front
rotors |
320mm |
| Rear
brake |
single
disc |
| Rear
rotor |
276mm |
Wheels & Tires
|
| Front
tire |
120/70-ZR17 |
| Rear tire |
170/60-ZR17 |
